    Product Details:

    Place of Origin: Changzhou City, Jiangsu Province, China
    Brand Name: UNIVERSAL TENT
    Certification: ISO9001:2008, SGS, TUV, etc.

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 sets
    Price: Negotiation
    Packaging Details: 1. membrane film. 2. Carton. 3. PVC carry bag
    Delivery Time: 15-30 working days after received deposit
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20,000sqm/month
    Contact Now
    Detailed Product Description
    Frame: Hard Pressed Aluminum Alloy 6061/T6 Color: White, Transparent, Silver Grey, Red, Yellow, Green, Black, Blue, Etc
    Top Style: Ridge Tent / Pagoda Tent / High Peak Tent Sidewalls: Soft PVC Walls, Glass Wall, ABS Hard Wall, Sandwich Hard Wall
    Wind Load: 70-100km/h Decoration: Lining , Curtain , Floor System , Etc
    Customized: Available Roof Cover: 650~950g/sqm, Block-out Double PVC Coated Fabric
    High Light:

    high peak canopy

    ,

    blue peak tents

    6x6m Aluminun Frame PVC Fabric Gazebo Canopy Tent / High Peak Pagoda Tent with Soft PVC Windows for Outdoor Party / Even



    Description:



    Gazebo tent is widely used for outdoor party, event, wedding, exhibition. An outdoor party with a party tent tends to be more beautiful and memorable, especially when you choose the ideal location where the sights and sounds compliment the whole event. Then Gazebo Tent is one of the best choice. A party tent make your big moment more special.



    Pagoda Tent is also called Pagoda Marquee or Chinese Hat Marquee, Pagoda marquees are available in a range of sizes from 3x3 to 10x10, and all with generous head height, pagoda tents offer a spacious and attractive setting for any occasion.



    UNIVERSAL TENT is an experienced tent supplier with creative and delicate solution in tent field. We focus on global PVC tents market and requirements and supply satisfactory and customized solution to our customers.



    Size of our Tent:



    Pagoda marquees / Pagoda Tents / High Peak Tents are available in a range of sizes from 3x3 to 10x10, any customized size is available.



    Span Width Bay Distance Eave Height Ridge Height Main Profile
    3m/9.8' 3m/9.8' .2.5m 4.3m 65X65X2.5m(4-channel)
    4m/13' 4m/13' 2.5m 4.8m 65X65X2.5m(4-channel)
    5m/16.4' 5m/16.4' 2.5m 5.43m 65X65X2.5m(4-channel)
    6m/19.7' 6m/19.7' 2.5m 5.92m 65X65X2.5m(4-channel)
    8m/26.2' 8m/26.2' 2.6m 5.36m 122X68X3mm(4-channel)
    10m/32.8' 10m/32.8' 2.6m 6.38m 122X68X3mm(4-channel)
    The length can be extended by 5m bay such as 15m,20m,30m,40m...Customized size or shape is available.



    l



















    Structure


    Framework: hard pressed extruded aluminum 6061/T6(15HW) which can last more than 20 years.
    Fabric Cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
    Connector: strong hot-dip galvanized steel
    Allowed Temperature Condition: -30 degree Celsius~+70 degree Celsius
    Wind Loading: 70 -100km/h (can be reinforced)
    Snow Loading: 30kg/sqm (snow can't stay if use big degree roof pitch design)
    Easy to be assembled and dismantled, movable.
    No pole inside, 100% available interior space.





    Applications:



    Widely used for parties, weddings, events, celebrations, sports, trade shows, warehouse, Hajj, conferences, cafe shops, restaurants, corporate events, etc.



    Fixing Methods:



    If it is concrete ground, pls use the expandable bolts.

    If it is tarmac ground or grass ground, sand ground or other soft grounds, pls use the steel anchors;

    If it is plates system.

    If you will make the concrete bases to fix the tent, pls use the embeded bolts M24x500mm.

    marble or tile ground or other kind indestructible grounds, pls use the weight



    Accessories:



    Tent Covers: different colors for your choose, transparent cover

    Side Windows: arch or square clear PVC windows, mesh window, glass window

    Wooden Flooring System: VIP cassette flooring, simple cassette flooring

    Doors: double-wing glass door, single-wing glass door, glass fire door, aluminum door, rolling shutter(automatic or manual)

    Side Walls: soft PVC fabric wall, glass solid wall, ABS hard wall, sandwich panel wall, steel plate wall

    Interior decoration: roof lining, side curtains, different colors and designs are available

    Fixing Methods: steel pegs, weight plate, expandable bolts

    Rain Gutters: inner roof beam rain gutter or rain gutter between two similar tents

             Optional Items: table, chair, lighting, AC, carpet, installation tools, booth, mobile toilet, etc.
